Plastic Bag Washing Machine For Plastic Recycling Machines

  • Plastic Bag Washing Machine For Plastic Recycling Machines
  • Plastic Bag Washing Machine For Plastic Recycling Machines
  • Plastic Bag Washing Machine For Plastic Recycling Machines
  • video
Plastic Bag Washing Machine For Plastic Recycling Machines
  • ACE WashTech
  • China
  • 45 days
  • 100 sets

Higher output and lower energy consumption.
Low water consumption, 95%recycled-release.
Lower investment cost for a high quality and durable machine.
Auto control system.
Control mofule system.
Fast machine delivery and installation.

INTRODUCTION


Ability

Thanks to innovative washing technology and high quality performance.   Removes the most difficult contaminants from PP/ PE/ PS/ ABS plastic materials. Cleans post consumer film, agricultural film, Rigid bottle/ drum, Battery case, WEEE plastic and even heavily contaminated woven bag fibre material. Provides almost 100% purity washing results.



Stability

Plastic washing Recycling Line is available for 24 hours working non-stop operation. Optimized design and top brand components to each module. Which could minimize the downtime ratio and save the maintenance time. This ensures the maximum availability and highest productivity for user.



Efficiency

Plastic washing Recycling Line is designed in all details for efficiency improving. The modular design could simplifies the planning and accelerates the implementation. The system have very low consumption values for electricity, water and chemicals. The operating costs and maintenance costs are absolutely reduced. Consistently the lowest investment costs and highest value creation!



Modularity

Plastic washing Recycling Line is a flexible modular system. All elements required by any customer for different application could be combined freely. This design reduces planning, construction and assembly time effectively. And it’s possible to adjust the system with regard to technological modification and market changing. This makes the investment future-proofing!



Intelligent control

Intelligent automatic modular control of Plastic washing Recycling Line. One main control panel with modern Touch Display for efficient interaction of all component. Multi-language available for operating system.



Turnkey service

Plastic washing Recycling Line is a flexible and customer-oriented recycling solution. The proposal is integrated and engineering project. Building design, overseas installation, commissioning and training are available. Machine warranty with spares in stocking and in-time delivery. Consistently quick and careful service in pre-sales and after-sales process.

300kg/h capacity PP film washing system

BASIC DATA OF WASHING

ModelECO 300
PRO 300ECO 500PRO 500 ECO 750
PRO 750ECO 2000
PRO 2000
Capacity for film220-350 kg/h
220-350 kg/h450-550 kg/h450-550 kg/h750-1000 kg/h750-1000 kg/h1800-2200 kg/h1800-2200 kg/h
Installed power163 KW167 KW215 KW223 KW168 KW362 KW744 KW910 KW
Working power114 KW121 KW161 KW167 KW126 KW271 KW560 KW700 KW
Fresh water consumption0.5-1 m3/h0.5-1.5 m3/h0.5-2 m3/h1-2.5m3/h3-5 m3/h3-5m3/h8-10 m3/h8-10 m3/h
Moisture of output<7%<7%<7%<7%<7%<7%<7%<7%
Operation staff33334-55-65-65-6
Dimension (L*W*H)M18*4*820*4*822*4*836*4*847*4*858*5.5*874*6.5*883*6.5*8



FAQ
What should I offer for the most suitable solutions?
Please provide the capacity you required and the picture of raw material, which can help us to confirm the condition of the raw material. Different materials have different processing programs....more
